Specifications

Rated Output

3.0mV/V±0.003

Input impedance

775±20Ω

Non-linearity

±0.05%F.S

Output impedance

700±5Ω

Hysteresis

＜±0.05%F.S

Insulation resistance

≥5000MΩ

Repeatability

＜±0.05%F.S

Allow excitation voltage

5～15V/DC

Creep

＜±0.05%F.S/30min

Compensated temp. range

-10℃～+40℃

Temp. effect on zero

＜±0.03%/10℃

Operating temp. range

-30℃～+70℃

Temp. effect on output

＜±0.03%/10℃

Safe overload

150%F.S

Zero balance

＜±1%F.S

Ultimate overload

300%F.S

Connection

Excitation：+ Red - Black Shield： Thick Yellow Signal： + Green - White
